4V420-15 Solenoid Valve

4V420-15 Solenoid Valves ni hpe, hkrak tup hkang zing ai lam hte lawan ai hku bai htang ai aten ni hpe hkrak hkrak hkang lu ai ladat ni, hpaga lam ni, galaw shapraw ai shara ni hta ayan lang ai.

Amyu	masat da ai lam
Standard voltage	AC220V	AC110V	AC24V	DC24V	DC12V
Voltage a shingjawng ai lam	AC:±15% DC:±10%
dat kasa jai lang ai lam	3.5VA	3.5VA	4.0VA	2.5W	2.5W
Makawp daw;	IP65(DIN40050)
Temperature garan ginhka ai lam	B Class
wan hku shang ai lam	Ga si,Grommet
Activate galaw ai aten	0.05 sec hte lawu na .

Kasi	hkrang	Valve hpan	Hka daru hkrang	Voltage	shara galai ai	Ri hpan
4V:Selenoid valve (5/2,5/3 hku).	1:100 Series	10:Single solenoid 5/2 ladat 20:Double solenoid 5/2 ladat 30C:Law n-gun rawng ai solenoid 5/3 lam pat da ai ginjaw 30E:Double solenoid 5/3 lam n-ut/wang 30P:Double solenoid 5/3 lam n-gun n-gun ginjaw	M5:M5	A:AC220V B:DC24V C:AC110V E:AC24V F:DC12V	Blank:Terminal Ngai:Grum	n rai ndai code
			06:1/8"			Blank·PT G:G T:NPT
